FPS-PB500 Commercial Flake Ice Machine Specifications
Core Performance
Ice Production: 500 kg/24h (±5%) → 20.8 kg/hour peak output
Ice Storage: 150 kg SUS304 stainless steel bin (triple-insulated walls)
Thermal Efficiency: 4.74 W/kg energy ratio (industry-leading)
Power & Compression
Supply: 220V (±10%) / 50Hz (industrial voltage tolerance)
Consumption: 2370W (Power Factor ≥0.93)
Compressor: Danfoss MT-Series (40,000hr MTBF rated)
Thermal Management
Dual Cooling System:
Air-cooled operation: ≤35°C ambient (auto-switch threshold)
Water-cooled activation: >35°C environments
Operating Range: 5°C to 43°C ambient / ≤85% humidity (tropical certified)
Environmental Compliance
Refrigerant Options:
R404A (GWP=3923 | EPA/CE compliant)
R22 (Legacy system support | GWP=1810)
Material: Anti-corrosion SUS316 exterior (food-contact zones SUS304)
The FPS-PB500 commercial flake ice machine is a high-performance solution for businesses that need large volumes of flake ice every day. It produces up to 500Kg of flake ice per 24 hours. A built-in storage bin holds 150Kg of ice, ensuring a steady and reliable supply for continuous commercial use.
Made from food-grade stainless steel, the FPS-PB500 is built for durability, hygiene, and long-term operation. It features a powerful Danfoss compressor and supports both air cooling and water cooling. This flexibility allows for easy installation in various commercial environments. The unit runs on a 220V/50Hz power supply and uses either R404A or R22 refrigerant, both efficient and environmentally friendly.
With dimensions of 760×850×1850mm, this commercial flake ice machine fits well into space-conscious setups. It’s ideal for seafood markets, food processing plants, commercial kitchens, and supermarkets. Despite its high output, the FPS-PB500 remains energy-efficient. It ensures stable performance with reduced downtime and lower operating costs.
Whether you’re preserving seafood, chilling meat, or handling temperature-sensitive foods, the FPS-PB500 delivers high-quality flake ice—fast, efficient, and dependable.
FEIPULI is dedicated to providing the simplest, most reliable and easy-to-use commercial ice machines.
